90BBL Cylindro Conical Beer Fermenter

A 90 BBL Cylindro Conical Beer Fermenter is a large-scale fermentation vessel used in commercial brewing, but it is large beer fermentation tank compared to the 3000L unitank.The “cylindro-conical” design refers to the shape of the tank, which has a cylindrical upper section that transitions into a conical bottom.

Specification for 90bbl cylindro conical beer fermenters as follows:

• Beer unitanksw/ 25% head space.
• Design pressure 30psi or 2
• Interior shell: SUS304, thickness 3mm.
• Exterior shell: SUS304, thickness 2mm.
• Interior and exterior finish bright polish to 2B, hygienic surface.
• 60° conical cone bottom.
• Racking port and discharge port with butterfly valve and fittings.
• Side or Top man way door, shadowless.
• Dimple glycol cooling jackets with glycol inlets and outlets.
• Polyurethane foam insulation, thickness 100mmon side and bottom.
• Fully welded exterior shell.
• 4 legs with levelling foot pads.
• CIP arm and spray ball.
• Rotating racking arm.
• Vacuum relief at 2bar.
• Pressure relief valve at 30psi as standard.
• Sanitary pressure gauge.
• 5”sample valve.
• Beer fermenters come with fittings, valves, and all parts.
• Lifting Lugs.
• P100 temperature sensor.
• 2’’Carbonation stone.
• 6’’or 8’’ Dry hopping port
• 24V DC liquid solenoid valve.

OPTIONS:

• Additional blow off pipework.
• Larger drain ports.
• Tangential inlets.
• Glycol pipework.

Advantage for our 90bbl cylindro conical beer fermenters  ：

Certified stainless-steel material. Sanitary construction with 100% TIG welded joints and seams with sanitary interior polish. All beer fermenter tanks and jackets inspected and pressure tested to 2 times operating pressure. All beer fermenters insulated with high efficiency polyurethane foam. We can custom fabricate any beer brewery tanks to meet your brewery’s space and height restrictions. Beer fermenters design pressure is 30 PSI。
